Cerakote Finishing
Ceramic Finishes for Durability and Style
Cerakote is a ceramic based finish that can be applied to metals, plastics, polymers and wood. The unique formulation used for Cerakote® ceramic coating enhances a number of physical performance properties including abrasion/wear resistance, corrosion resistance, chemical resistance, impact strength, and hardness.
What are the disadvantages of Cerakote?
One disadvantage of Cerakote is that, while it helps protect against rust, it's not rustproof — no coating is. When we sharpen our blades or laser our logo, we expose the steel to oxygen, creating a place where rust can start. Another disadvantage is that Cerakote wears less gracefully than Parkerizing.
How long does Cerakote last?
You don't have to worry about it peeling or flaking off over time. A Cerakote finish should last for several years if it is applied correctly.
WARNING!!!! WE MUST KNOW IF YOUR STOCK IS FIBERGLASS….
Fiberglass is unpredictable when baked and we recommend NOT doing anything that is fiberglass.
We will coat your fiberglass stocks and parts with C-series but We are NOT responsible for anything that happens to fiberglass parts if you choose to them done.
Tight Tolerance Parts and Markings:
We do not coat sears, springs, bores/chambers or other tolerance critical or high-flex parts such as rubber pistol grips.
We do not media blast scopes or other optics therefore, the adhesion of the Cerakote will not be as good on those items.
TOLERANCE: For standard firearms applications it is often inadvisable to coat both pins and pin holes, as the resulting one (1) mil thickness of the coating when applied to surfaces creates an increase of two (2) mil to the part tolerance and four (4) mil (.004) when both hole and pin are coated. This is also applicable to auto-pistol slide and frame fit, such as on tight-fitting 1911’s. We typically plug or mask holes and pins and only coat the pin ends. However, we can coat pins and holes and then custom fit these parts after coating for an additional charge. We recommend hand fitting and lapping for 1911 pistol slides and frames as this will yield a precision fit and can help to tighten looser fitting slide/frame combos.
MARKINGS: For receivers, frames, slides, Picatinny rails which have painted on or lightly laser etched markings these markings will be lost during the surface preparation and coating unless they are machine engraved or stamped. If these markings are of great importance we can mask over them, but those areas in and immediately around the markings will not be coated and, as such, will not blend. Manufacturer’s serial numbers will be masked at no additional charge where needed or coated where possible. Some manufacturer model numbers, name etc which are laser engraved will be masked over. This is per BATFE (ATF) regulations. Please consult us for specific requirements.
Cerakote H-Series:
H-Series is the most durable of the standard Cerakote family of coatings and provides the best performance in hardness, wear and scratch resistance, adhesion and rust resistance. It can withstand heat up to 500f – 600f degrees and comes in the widest range of colors. Therefore, we use the H-Series wherever possible. However, it’s a two-part heat cure finish and, therefore, cannot be applied to optics and other items or substrates which cannot, or should not be cured at the required temperatures.
Cerakote™ C-Series:
For high-temp applications up to 1700°, such as suppressors and machinegun barrels, Cerakote™ C-Series has no equal. It’s available in a wide range of colors to match the overall finish requirement of the firearm or weapons system. We also use C-Series to coat scopes and other optics, as well as fiberglass and items and substrates which cannot be baked. It is not as durable as the H-Series and is less scratch and wear resistant. The primary application is optics, electronics and fiberglass stocks which cannot be hear cured.
Cerakote Micro Slick
Is a dry film ceramic coating with special properties and attributes specially suited to tight tolerance applications and high-wear internal parts, such as bolts, bolt carriers, barrels and 1911 barrel bushings, etc… Cerakote Micro Slick penetrates the metal substrate and therefore adds minimal (.25 to .50 mil) thickness. Micro Slick came out of NIC’s industry leading Micro Dyne automotive and turbine coatings division where it has been used successfully for many years to coat automotive pistons, cylinder walls and turbine blades, etc. Cerakote Micro Slick provides outstanding anti-friction and wear-reduction properties and good rust prevention properties. In addition when applied to certain internal firearms parts, helps to reduce carbon fouling by resisting carbon adhesion, which promotes reduced maintenance, easier cleaning and improved operational reliability. Micro Slick imparts a medium grey to dark grey/black color to most steel substrates. Its primary purpose is one of functionality rather than aesthetics as the parts will “burnish” over time changing the original coated appearance of the parts while maintaining the anti-friction and anti-carbon attributes of the coating.
CERAKOTE STANDARD PERFORMANCE METRICS:
RUST RESISTANCE: Cerakote™ finishes have been tested in salt spray and full emersion and have withstood beyond 3,000 hours in salt spray and hundreds of hours in full emersion testing. These results outperform other finishes by over 10x. This makes Cerakote™ finishes the clear choice for marine environments and other environments subject to high humidity and salt water environments.
WEAR RESISTANCE: Cerakote™ finishes can withstand over 5,000 (5,212) wear cycles per mil (.0001). The Tabor wear test uses an 8″ abrasive wheel applied to a metal plate coated with 1 mil thickness of the Cerakote coating. In addition, Cerakote’s Coefficient of Friction is 80% less than stainless steel against stainless steel. So, when one or both moving parts of a firearm are coated you can expect a significantly longer product duty cycle or service life.
ADHESION: Cerakote finishes have an ASTM D3359 rating of 5B and can withstand a 180° mandrel bend rotation test around a 1/4″ mandrel and a ball bearing impact test of 160 inch-lbs with no cracking or loss of adhesion. This is significant performance given Cerakote’s 9H pencil hardness, which is the highest hardness rating in the scale.
HARDNESS AND SCRATCH RESISTANCE: ASTM D3363 is a 9H pencil hardness and 6H scratch resistance.
FILM THICKNESS: 1.0 mil (Cerakote Micro Slick is .25 to .50 mil)
